BFS series backpack type constant pressure water supply
BFS series backpack type constant pressure water supply
BFS series piggyback inverter
| classification | Specific parameter items | Details |
|---|---|---|
| power range | power and voltage | 0.75KW - 15KW, applicable voltage 380V |
| Product overview | product positioning and function | Company's automatic one-button operation series products have constant pressure water supply and automatic fool operation, which can easily set water supply parameters (target pressure, sleep pressure, etc.), have water supply functions such as underpressure and overpressure instantaneous, and the parameters are directly displayed and operated in Chinese. |
| Product Features | automatic flow stabilization | Automatic flow stabilization function to ensure that the machine will not stop due to slight overload |
| Automatic voltage adjustment | When the grid voltage changes, automatically keep the output voltage constant | |
| PZD adjustment function | to achieve precise control of the motor | |
| communication function | provides RS485 physical communication terminal interface, using standard Modbus protocol | |
| Carrier Function | provides random carrier function to reduce operating noise | |
| Carrier Frequency Adjustment | carrier frequency 1 - 15KHz adjustable, configured by the model | |
| power range | 0.75KW - 15KW | |
| Water Supply Function Design | rich water supply function design | |
| frequency conversion control | frequency conversion constant pressure, automatic voltage stabilization, precise control of water supply pressure | |
| Water pump protection function | All-round water pump protection function (phase loss, overvoltage, undervoltage, overload, etc.) | |
| operation and function setting | Easy operation, complete function settings | |
| Incoming call restart | power-off memory calls automatically restart | |
| water shortage protection | water shortage automatic shutdown protection pump | |
| Optional Configuration | Optional remote APP wireless float device |
piggyback inverter product overview
Backload inverter is a series of automatic one-button operation products of the company. It has the characteristics of constant pressure water supply and automatic fool operation. It can easily set water supply parameters (including target pressure, sleep pressure, sleep frequency, sleep delay, wake-up pressure, wake-up delay, etc.). It also has functions required for water supply such as undervoltage and overvoltage instantaneous. The parameters can be direct
Backload inverter is a series of automatic one-button operation products of the company. It has the characteristics of constant pressure water supply and automatic fool operation. It can easily set water supply parameters (including target pressure, sleep pressure, sleep frequency, sleep delay, wake-up pressure, wake-up delay, etc.). It also has functions required for water supply such as undervoltage and overvoltage instantaneous. The parameters can be direct
